U shaped Screw Conveyor

Category: Screw conveyor

Description: U shaped screw conveyor is a major conveying equipmentwidely used in kinds of industry.

Product Description:

U shaped Screw conveyor, which is designed according to standard of  JB/T679-95 screw conveyor. The machine features high reliability, long lifetime, good applicability, convenience to install and maintain.The temperature of materials can reach up to 100 °C, the biggest dip angle can be up to 45°.The Screw Conveyor is a conveyor device, which utilizes the rotation of the helical axis in the U-groove to achieve the delivery of materials.

Machine Structure:

Technical Parameter:

screw conveyor
Rated speed
Reference capacity
Motor power
Admission biggest gradient
LS114 114 84-130 1 0.75-18.5 <60
LS133 133 84-130 1.3 0.75-18.5 <60
LS159 159 84-130 5 0.75-18.5 <60
LS219 219 84-130 15 0.75-18.5 <60
LS245 245 84-130 20 0.75-18.5 <60
LS273 273 84-130 30 0.75-18.5 <60
LS315 315 84-130 40 0.75-18.5 <60
LS400 400 60-100 45 0.75-18.5 <60
LS500 500 60-100 70 0.75-18.5 <60
LS600 600 60-100 100 0.75-18.5 <60


It is used to convey and stir materials of powder, granular or small block in industry, medicine, food and environment protection industries and can control the quantity of flow of materials by adjusting rotate speed.

Our service:

Pre-sale services:
a. Professional engineer design the production line for you.
b.Recommend suitable equipment according to your special demand.
During-sale services:
a.Pre-check and accept products before delivery.
b.Send technicians to the jobsite for guiding the installation and adjustment.
c.Training operators and finishing the check to satisfy your requiremnet.
After-sale services:
a.Common problem can be solved through web in 24 hours,complex problem can be reacted immediately in 24 hours and solved as soon as possible.
b.To establish long-term friendship, we will regulary contact with our customers.

How to purchase our products:

Could you please tell me that what model do you need?If you cann`t confrim it,as the professional manufacturer,our engineers can according to your specifications for your particular manufacturing.Please give me and confrim the following parameters so that we recommend suitable model for you and then quotation.
 1.the name of material?
 2.How much is the hourly output?or tell me that the diameter of screw?
 3.the material of equipment:
  a.304 stainless steel b.carbon steel
 4.Whether there are a angle for screw,if it have a angle,pls tell me.If you cann`t confrim this angle,pls tell me the horizontal distance from inlet to outlet or the height from output    to ground.
 5.About motor?
 6.Other special design?
If you have any needs or requirements,pls contact me without hesitate!!!
